Cold forging press

KT Series

Knuckle-Joint 1-Point Transfer Presses

The KT Series press is a multi-process continuous production and automation machine with integrated automatic control devices, enabling a single operator to manage the production of multiple line products and even achieve unmanned production mode.
In continuous multi-process processing, automated feeding completes the entire sequence, eliminating the need for intermediate handling. With no inventory of semi-finished products, it avoids wasting production space and reduces management complexity.
When adopting automated production methods, the production efficiency can be increased by more than three times compared to single-process operations.

Application

Bicycle Main Forging Parts

Automobile Sheet Metal

Standard Accessories

Slide and die balance device	Electric grease lubrication device
Electric slide adjustment device (with hydraulic locking)	PLC programmable controller • Electronic rotary cam switch (prepared for 6 pairs) • Electronic crank angle indicator / Stroke counter • Electronic stroke counter / Pre-set counter (6 digits each)
Centralized circulation lubrication oiling device	Safety guard and safety ladder
Second-stroke protection device	Air blow joint 3/8"
Load detection (safety) device	Air source joint 3/8"
Digital mold height indicator (unit: 0.1mm)	Maintenance tools and toolbox
Misfeed detection circuit	Operating instructions & precision inspection table
T-shaped worktable

Optional Accessories

Press controller MPC Series	Power socket 110V / 220V single phase (customer supplied)
Photoelectric safety device	Shock absorber
Upper slide material feeder	Foundation screws and foundation plate
Crank angle indicator (clock type)	Rotating operating panel
Electronic rotary cam switch (prepared for 8 pairs)	Attached detection dual solenoid valve
Inverter	Quick die change device
Foot switch (with certificate)	Automatic feeding device
Die illumination light
