The SC1 series features an ultra-high rigidity straight-column reinforced frame, optimizing structural rigidity, significantly enhancing the precision of stamped products, and effectively extending the lifespan of dies.
| Standard Accessories | |
| T-type worktable | Electric grease lubrication device |
| Punch press controller (PLC + HMI) ● Electronic crank angle indicator ● Electronic operation speed indicator ● Operation status LCD monitor |
Accumulative counter 6 digits |
| Operation mode selection Cut / Inch / Safe Single Stroke / Continuous |
Pre-set counter 6 digits |
| Hydraulic overload protection device | Maintenance counter 4 digits (unit: ten thousand) |
| Second-stroke protection device | Life counter 10 digits |
| Electrical cabinet door power-off switch | Electronic rotary cam switch with 6 positions reserved |
| Dual-channel solenoid valve | Air blowing device 3/8” |
| Electric slide adjustment device | Air supply connector 3/8” |
| Main motor forward and reverse device | Misfeed detection metal socket |
| Digital die height indicator (unit: 0.1mm) | Power socket 110V or 220V single phase (customer-supplied power) |
| Optional Accessories | |
| Die cushion device | iForming Intelligent Forming Productivity Management System |
| Top material feeding device for slide | Feed shaft end Left side take-off type (feeding direction: left → right) |
| Safety blocks and safety pins | Quick Die Change System (Q.D.C.S.) |
| Attached misfeed dual-channel solenoid valve | Foundation screws and foundation plate |
| Cutting counter 3 digits | Anti-vibration device |
| Flywheel brake device | Die illumination light |
| Load detection (safety) device | Foot switch (with affidavit) |
